BIOMATTONE® SYSTEM GUIDE
Biomattone® in Bolzano: Formats, Prices and Technical Data
Biomattone in Bolzano: discover the 8 available formats (BA8-BA50) and thermal transmittance U from 0.50 to 0.09 W/m²K. Then request a quote for the TecnoCanapa Bioedilizia® Biomattone® hemp-lime system.
Biomattone in Bolzano: formats, prices and technical data
Composition and function in natural building
Biomattone for Bolzano is shipped throughout Italy from the Senini plant in Novagli di Montichiari (BS). Choosing the right format is crucial in harsh climates: BA36 offers U = 0.12 W/m²K with a phase shift of 22h23′, while BA50 reaches U = 0.09 W/m²K with a phase shift of 32h04′. To learn more about thermal transmittance criteria, you can also consult ANIT; the complete system is described on the Biomattone® home page.
- composition
- function
- applications
- performance
- installation
THE SOLUTION
Biomattone® for new builds and retrofits
Biomattone® combines hemp shiv and a natural binder in a single building envelope solution.
The combination of insulation and mass gives the building envelope a dynamic behavior. It is not just insulation: it is also the ability to delay and dampen peak heat. Insulating with mass therefore means stabilizing. The BIOMATTONE® envelope system is thus a mineral-plant masonry with hygroactive behavior, which insulates and stabilizes indoor thermo-hygrometric conditions.
Applications of the Biomattone® system
This construction solution is consistent with the principles of durability, maintainability and passive reduction of energy demand.
The BIOMATTONE® envelope system contributes to the building's environmental balance through CO₂ storage certified by an Environmental Product Declaration (EPD).
Biomattone® performance in the complete system
DOCUMENTED CONTENT
CONSTRUCTION SYSTEM
The building system beyond the single block
The result depends on coordination between structure, building envelope, finishes, junctions and installation.
In fact, for an innovative yet durable home. A reinforced concrete structure consists of reinforcement (steel bars tied together to form a cage) and a concrete pour that encases the steel core. Thanks to its considerable compressive and tensile strength, reinforced concrete is used both for buildings and for infrastructure such as bridges, tunnels, roads, dams and railways.
In short, the combination of the innovative drive of one and the solid structure of the other gives rise to a business that develops construction solutions based on a lime-hemp biocomposite – Bio Beton® and Biomattone® – aimed at achieving high quality standards for the building envelope and the living environment.
- load-bearing structure;
- building envelope;
- finishes;
- junctions;
- installation.
Sustainability, comfort and durability
Available formats and configurations
BA8
50x20x8
BA12
50x20x12
BA20
50x40x20
BA25
50x20x25
BA30
50x20x30
BA36
40x20x36
BA40
50x20x40
BA50
40x20x50
Analysis, configuration and technical support
Building with Bio Beton® or Biomattone® delivers high thermal performance of the building envelope, with minimal heat loss and excellent indoor comfort for almost the entire year. As a result, the energy needed to maintain indoor comfort during the coldest weeks of winter or the hottest weeks of summer is kept to a minimum.
1. Analysis
Building, structure, application and goals.
2. Configuration
Format, wall build-up, finishes and details.
3. Support
Documentation, technical discussion and installation.
BIOMATTONE® TECNOCANAPA BIOEDILIZIA®
Biomattone in Bolzano FAQ
What is Biomattone® Tecnocanapa Bioedilizia®?
Biomattone® is a prefabricated hemp-lime block. It is used for masonry and insulation. It combines coarse hemp shiv, a natural dolomitic binder and a probiotic additive. It is available in 8 formats, from BA8 to BA50, with thicknesses from 8 to 50 cm. This makes it suitable for vapor-permeable, insulating walls in Bolzano as well.
When is this system recommended?
It is the right choice when you want thermal insulation, thermal mass and vapor permeability in the same wall. For example, in insulating infill walls. It also works as internal or external insulating lining walls on existing masonry. It is also used for internal partitions with sound insulation and for subfloors. The choice depends on the building and the project goals: for Bolzano, the technical specialist assesses it together with the designer.
What advantages does it offer?
It combines several functions in a single element. Its thermal conductivity is 0.044 W/mK. Its dry density is 310 kg/m³ and its specific heat capacity is 1280 J/kgK. Vapor permeability is high (μ 4.5). Sound absorption is Class A and reaction to fire is B-s1,d0. For example, BA50 reaches U 0.09 W/m²K and a phase shift of 32h04′ (without plaster).
Is it suitable for renovations?
Yes, the system is also used in renovations. It works as an internal or external insulating lining wall on existing masonry. Thicknesses range from 8 to 50 cm. The format therefore depends on the available space and the required performance. The application and thickness must in any case be verified for the specific project in Bolzano.
How is the wall build-up defined?
The wall build-up depends on the structure, climate zone, finishes and required performance. The technical specialist starts from the chosen format. For example, U ranges from 0.5 to 0.09 W/m²K, and the thermal phase shift ranges from 3 to over 32 hours, without plaster. They then check construction junctions, laying mortar and vapor-permeable coatings.
More questions about Biomattone in Bolzano
What technical data is available for Bolzano?
The technical data sheet gives the thermal transmittance (U-value), thermal resistance (Rt) and thermal phase shift for all 8 formats (BA8-BA50), as well as density, conductivity (λ=0.044 W/mK) and fire resistance. This data is useful for energy calculations in cold climate zones such as Bolzano.
Is technical support available?
Yes, TecnoCanapa Bioedilizia® supports designers, contractors and clients. It assists with format selection, wall build-up, construction junctions and installation. So for a project in Bolzano you can request a technical assessment or download the data sheet.
How do you choose the format in Bolzano?
For harsh climates like Bolzano’s, greater thicknesses are preferred: BA30 (U=0.14 W/m²K), BA36 (U=0.12 W/m²K, phase shift 22h23′) or BA50 (U=0.09 W/m²K, phase shift 32h04′). However, the final choice depends on the wall build-up, orientation and the project’s performance target.
How do you request an assessment?
Use the contact buttons on this page. Tell us the location, type of project, available thickness and performance goals. The technical specialist then assesses the application, format and wall build-up. A quote is available on request and depends on the format, quantity, wall build-up, logistics and installation.
How do you get the technical data sheet?
Use the «Download the Biomattone® technical data sheet» button on this page. The data sheet covers composition, formats, thermal transmittance and thermal resistance. It also gives the system’s thermal phase shift and sound reduction.
